LED driver power supply ZNDR 12W 12V 1.3A images
Power supply for powering LED strips 12V 12W PFC
AC mains voltage:
AC 220 -240V
AC mains frequency:
50-60Hz
Stabilized DC output voltage:
12 V
Maximum continuous output power:
12W
Maximum output current:
1A
Operating temperature:
max 40°C
Energy processing method:
PFC switching power supply
Protection :
overload (OCP), overvoltage (OVP), short-circuit (SCP), thermal (OTP)
IP degree:
IP20
Connection method:
terminal blocks tightened with screws
max cross-section of the wire 0.75mm2
max cross-section of the wire 0.75mm2
External dimensions:
90x41x19mm
Certificates:
CE, RoHS
The power supply is intended for indoor use. The product is made ofhigh-quality componentsthat have been placed ina solid plastic housing. The power supply is designed to power LED lightingwith a voltage of 12Ve.g. LED strips, integrated fixtures, and bulbs. The PFC type converter optimizes the reactive power consumption from the grid. The use of a transformer galvanically isolates the load from the power grid, which is essential for electrical safety. Cooling occurs through free air circulation. The modular design allowsfor easy and convenient installationon both vertical and horizontal surfaces with two screws of max. diameter 3mm. The output voltage of 12V is safe for people.
